Clean Air Equipment

Biosafety Cabinet

Model: LFAS-112

Class II biosafety cabinet providing personnel, product, and environmental protection.

Custom-built to your specifications
Pre-dispatch quality testing
Installation & training support
Comprehensive manufacturer warranty

Product Overview

100% air exhaust Negative pressure air surrounding all biological contaminated parts Class II, Type B2 cabinets are total exhaust cabinets, widely used in toxicology laboratories and similar applications where chemical effluent is present and clean air is essential. There is no recirculation within the work area. Room air enters through a blower/motor in the top of the cabinet and passes through a HEPA supply filter into the work area as the vertical unidirectional airflow.

Descending air is pulled through the base of the cabinet through the perforated front and rear grilles. Simultaneously, air entering through the perforated front opening is pulled through the grille and exhausted immediately,

100% of the air is pulled into the facility exhaust system for appropriate trident. Type B2 cabinet are hard-connected to an exhaust system.

Negative pressure surrounds the work area with double wall plenums for protection.

Air drawn through pre-filter is made to pass through highly effective HEPA (High Efficiency Particular Air) filters MAIN/SUPPLY FILTER having efficiency rating as high as 99.99% with cold DOP and 99.97% with hot DOP, thus retaining all air- borne particles of size 0.3 micron and larger. The highly efficient HEPA filter maintains the optimum cleanliness and purity. Being equipped with the prefilled, it can extend the life of HEPA filter.

Aerodynamic airflow grills maintain safety and prevents block age.U.V and fluorescent interlock available Ergonomic and comfortable sloped front window for comfortable head and elbow rest position, thus reducing fatigue

Technical Specifications

Class II Type B2 BIOLOGICAL SAFETY CABINET	Class II Type B2 BIOLOGICAL SAFETY CABINET	Class II Type B2 BIOLOGICAL SAFETY CABINET	Class II Type B2 BIOLOGICAL SAFETY CABINET	Class II Type B2 BIOLOGICAL SAFETY CABINET	Class II Type B2 BIOLOGICAL SAFETY CABINET	Class II Type B2 BIOLOGICAL SAFETY CABINET	Class II Type B2 BIOLOGICAL SAFETY CABINET	Class II Type B2 BIOLOGICAL SAFETY CABINET	Class II Type B2 BIOLOGICAL SAFETY CABINET
Model	LFAS-112	LFAS-112	LFAS-112	LFAS-112	Model	LFAS-112	LFAS-112	LFAS-112	LFAS-112
Internal dimensions (WxDxH)mm	600x600x600	900x600x600	1200x600x600	1500x600x600	Internal dimensions (WxDxH)mm	600x600x600	900x600x600	1200x600x600	1500x600x600
MOC	internal Working Chamber : Stainless steel (SS-304) Exterior Cabinet : Cold Rolled Steel Duly Powder Coated or Stainless Steel (SS-304)	internal Working Chamber : Stainless steel (SS-304) Exterior Cabinet : Cold Rolled Steel Duly Powder Coated or Stainless Steel (SS-304)	internal Working Chamber : Stainless steel (SS-304) Exterior Cabinet : Cold Rolled Steel Duly Powder Coated or Stainless Steel (SS-304)	internal Working Chamber : Stainless steel (SS-304) Exterior Cabinet : Cold Rolled Steel Duly Powder Coated or Stainless Steel (SS-304)	MOC	internal Working Chamber : Stainless steel (SS-304) Exterior Cabinet : Cold Rolled Steel Duly Powder Coated or Stainless Steel (SS-304)	internal Working Chamber : Stainless steel (SS-304) Exterior Cabinet : Cold Rolled Steel Duly Powder Coated or Stainless Steel (SS-304)	internal Working Chamber : Stainless steel (SS-304) Exterior Cabinet : Cold Rolled Steel Duly Powder Coated or Stainless Steel (SS-304)	internal Working Chamber : Stainless steel (SS-304) Exterior Cabinet : Cold Rolled Steel Duly Powder Coated or Stainless Steel (SS-304)
Pre-Filter	Mounted on aluminum frame, of rating 20 microns	Mounted on aluminum frame, of rating 20 microns	Mounted on aluminum frame, of rating 20 microns	Mounted on aluminum frame, of rating 20 microns	Pre-Filter	Mounted on aluminum frame, of rating 20 microns	Mounted on aluminum frame, of rating 20 microns	Mounted on aluminum frame, of rating 20 microns	Mounted on aluminum frame, of rating 20 microns
supply / Main Filter	HEPA (Efficiency 99.97% @0.3 microns to meet air quality ISO Class 4 equivalent to US FED STD 209 E, Class 10	HEPA (Efficiency 99.97% @0.3 microns to meet air quality ISO Class 4 equivalent to US FED STD 209 E, Class 10	HEPA (Efficiency 99.97% @0.3 microns to meet air quality ISO Class 4 equivalent to US FED STD 209 E, Class 10	HEPA (Efficiency 99.97% @0.3 microns to meet air quality ISO Class 4 equivalent to US FED STD 209 E, Class 10	supply / Main Filter	HEPA (Efficiency 99.97% @0.3 microns to meet air quality ISO Class 4 equivalent to US FED STD 209 E, Class 10	HEPA (Efficiency 99.97% @0.3 microns to meet air quality ISO Class 4 equivalent to US FED STD 209 E, Class 10	HEPA (Efficiency 99.97% @0.3 microns to meet air quality ISO Class 4 equivalent to US FED STD 209 E, Class 10	HEPA (Efficiency 99.97% @0.3 microns to meet air quality ISO Class 4 equivalent to US FED STD 209 E, Class 10
Exhaust Filter	HEPA (Efficiency 99.97% @0.3 microns to meet air quality ISO Class 4 equivalent to US FED STD 209 E, Class 10	HEPA (Efficiency 99.97% @0.3 microns to meet air quality ISO Class 4 equivalent to US FED STD 209 E, Class 10	HEPA (Efficiency 99.97% @0.3 microns to meet air quality ISO Class 4 equivalent to US FED STD 209 E, Class 10	HEPA (Efficiency 99.97% @0.3 microns to meet air quality ISO Class 4 equivalent to US FED STD 209 E, Class 10	Exhaust Filter	HEPA (Efficiency 99.97% @0.3 microns to meet air quality ISO Class 4 equivalent to US FED STD 209 E, Class 10	HEPA (Efficiency 99.97% @0.3 microns to meet air quality ISO Class 4 equivalent to US FED STD 209 E, Class 10	HEPA (Efficiency 99.97% @0.3 microns to meet air quality ISO Class 4 equivalent to US FED STD 209 E, Class 10	HEPA (Efficiency 99.97% @0.3 microns to meet air quality ISO Class 4 equivalent to US FED STD 209 E, Class 10
Electrical Socket	Electrical Socket is provided for using small electrical devices	Electrical Socket is provided for using small electrical devices	Electrical Socket is provided for using small electrical devices	Electrical Socket is provided for using small electrical devices	Electrical Socket	Electrical Socket is provided for using small electrical devices	Electrical Socket is provided for using small electrical devices	Electrical Socket is provided for using small electrical devices	Electrical Socket is provided for using small electrical devices
Power Supply	220/230 Volts AC supply	220/230 Volts AC supply	220/230 Volts AC supply	220/230 Volts AC supply	Power Supply	220/230 Volts AC supply	220/230 Volts AC supply	220/230 Volts AC supply	220/230 Volts AC supply
any Duty Exhaust System	Standard fitted to the system for 100% exhaust	Standard fitted to the system for 100% exhaust	Standard fitted to the system for 100% exhaust	Standard fitted to the system for 100% exhaust	any Duty Exhaust System	Standard fitted to the system for 100% exhaust	Standard fitted to the system for 100% exhaust	Standard fitted to the system for 100% exhaust	Standard fitted to the system for 100% exhaust
Any Tunnel/Duct (Option)	Available on per running feet basis	Available on per running feet basis	Available on per running feet basis	Available on per running feet basis	Any Tunnel/Duct (Option)	Available on per running feet basis	Available on per running feet basis	Available on per running feet basis	Available on per running feet basis
Sash Lift	Can be lifted and adjusted manually	Can be lifted and adjusted manually	Can be lifted and adjusted manually	Can be lifted and adjusted manually	Sash Lift	Can be lifted and adjusted manually	Can be lifted and adjusted manually	Can be lifted and adjusted manually	Can be lifted and adjusted manually
